HAEM09 Series IP20 CV 12/24/36/48V Emergency Converter Split Type 20W

HAEM09 Series IP20 CV 12/24/36/48V Emergency Converter Split Type 20W

Model Name:  HAEM09-M20VL



1. Emergency Wattage: 20W

2. Rich indicators, high quality and reliable.

3. Energy-saving, environmental, compact size and low cost.

4. Multiple protection measure: open circuit, short circuit, overload protection, etc.

5. Warranty: 3 years

6. Duration time 90 minutes.


0.00
0.00


Model Name:  HAEM09-M20VL



1. Emergency Wattage: 20W

2. Rich indicators, high quality and reliable.

3. Energy-saving, environmental, compact size and low cost.

4. Multiple protection measure: open circuit, short circuit, overload protection, etc.

5. Warranty: 3 years

6. Duration time 90 minutes.




Mode
EmergencyDALIDimmableCCTWireless
✔


Output

H:

220V Output

Emerency Convertor

M:

LED Driver& Emergency convertor

2 in 1

L:

Battery Built-in

Emergency Convertor

P:

Seperate Battery

Emergency Convertor


 ✔

Model

Input Rated Voltage

Output

Load power

Battery

Duration
HAEM09-M20VL

12-48VAC/DC

Constant Power

Output Power:

20W

Output Voltage:

DC12/24/36/48V


3-50W

11.1V 3600mAh


≥ 90min

Specification Dimention (unit: mm, tolerance: ±1mm)
ItemParameter
Rate Voltage12-48VAC/DC
Load power 3-50W
Charging Time ≤24 Hours
Discharge Power20W
Discharge ModeConstant Power
Discharge Time ≥90 minutes
Battery Pack11.1V 3600mAh
Protection Class Class II
Charging Current60-250mA
Protection

Over Charge/

Over Load/

Over Voltage

Ta 0-50℃
Tc 85℃
IP rating IP20
Warranty 3 years
